Saval 2-way flanged ball valves
Saval 2-way flanged ball valves
Details
Material selection
Design features
| Design |
Two-piece body, full bore DIN 13547 |
| F |
ace to face |
EN 558-1 Series 14 (DIN 3202 F4)
| Flages |
Flanges according to EN 1092 |
| Options for flange |
Flange for mounting of actuator ISO 5211 |
| Hydraulic tests |
Tightness and sealing according to EN 12266-1 |
Working conditions
| Size |
DN |
15 |
100 |
| Nominal pressure |
PN |
16 |
10 |
| Maximum pressure |
Up to 100ºC |
16 |
10 |
Design features
| Design |
Two-piece body, full bore UNE EN 1983:2014 |
| F |
ace to face |
EN 558-1 Series 14 (DIN 3202 F4)
| Flages |
Flanges according to EN 1092 |
| Options for flange |
Flange for mounting of actuator ISO 5211 |
| Hydraulic tests |
Tightness and sealing according to EN 12266-1 |
Working conditions
| Size |
DN |
15 |
100 |
|
Nominal pressure |
PN
10 |
16 |
| Maximum pressure |
Up to 100ºC |
9,4 |
15 |
Design features
| Design |
Two-piece body, full bore UNE EN 1983:2014 |
| F |
ace to face |
EN 558-1 Series 14 (DIN 3202 F4)
| Flages |
Flanges according to EN 1092 |
| Options for flange |
Flange for mounting of actuator ISO 5211 |
| Hydraulic tests |
Tightness and sealing according to EN 12266-1 |
Working conditions
| Size |
DN |
15 |
100 |
|
Nominal pressure |
PN
10 |
16 |
| Maximum pressure |
Up to 100ºC |
9,5 |
15,2 |
Optional features
| Integrated Logistics Support (ILS) |
Technical documentation (QR access)
Spare parts procurement (LCRS)
Logistics engineering (obsolescence / costs) |
More than a valve. A solution ready to evolve.
